Horizontal Machining Centre (HMC)

Heavy Duty NHM 8000

Travels (X/Y/Z): 1400 mm / 1050 mm / 1200 mm
Rapid Traverse Rates: 24 m/min (all axes)
Spindle: 8000 rpm, 35 kW power, 1732 Nm torque
Table & Load Capacity: 800 × 800 mm table, up to 2000 kg
Tool Changer: 60-tool ATC
Footprint & Weight: 7376 × 4325 × 3760 mm, 27 tons

Heavy Duty NHM 8000

Travels (X/Y/Z): 55.1 in / 41.3 in / 47.2 in
Rapid Traverse Rates: 945 in/min (all axes)
Spindle: 8000 rpm, 47 hp power, 1278 ft-lb torque
Table & Load Capacity: 31.5 × 31.5 in table, up to 4409 lb
Tool Changer: 60-tool ATC
Footprint & Weight: 290 × 170.3 × 148.1 in, 59,524 lb

Vertical Milling Centre (VMC)

High Precision DNM 6700

Travels (X/Y/Z): 1300 mm / 670 mm / 775 mm
Rapid Traverse Rates: 36 m/min (X & Y), 30 m/min (Z)
Spindle: 8,000 rpm high torque, 18.5 kW power
Table Size & Load Capacity: 1500 × 670 mm table, up to 1300 kg
Tool Changer: 40-tool ATC
Footprint & Weight: 3653 × 2356 × 3254 mm, 11 tons

High Precision DNM 6700

Travels (X/Y/Z): 51.2 in / 26.4 in / 30.5 in
Rapid Traverse Rates: 1417 in/min (X & Y), 1181 in/min (Z)
Spindle: 8,000 rpm high torque, ~24.8 hp power
Table Size & Load Capacity: 59 × 26.4 in table, up to 2866 lb
Tool Changer: 40-tool ATC
Footprint & Weight: 144 × 92.8 × 128 in, 24,250 lb

Horizontal Turning Lathe (HTL)

High Performance Turning Lathe LL20T L5

Max Turning Diameter: 320 mm
Max Turning Length (Between Centres): 500 mm (up to 625 mm)
Spindle Speed: 3500 rpm
Spindle Motor Power: 9 kW continuous / 11 kW (15 min rating)
Rapid Traverse Rates (X/Z axes): 30 m/min (X), 36 m/min (Z)

High Performance Turning Lathe LL20T L5

Max Turning Diameter: ~12.6 in
Max Turning Length (Between Centres): ~19.7 in (up to ~24.6 in)
Spindle Speed: 3500 rpm
Spindle Motor Power: ~12.1 hp continuous / ~14.8 hp (15 min rating)
Rapid Traverse Rates (X/Z axes): ~1181 in/min (X), ~1417 in/min (Z)

Coordinate Measuring Machine (CMM)

ZEISS Spectrum CMM

Measuring Volume: 700 × 1000 × 600 mm
Accuracy (MPE): 1.8 + L/250 µm (up to 1.7 + L/300 µm)
Angular Positions: 5° step = 5,184 / 2.5° step = 20,736
Sensors: RDS-CAA, VAST XXT, LineScan One (optical)
Software: ZEISS CALYPSO

ZEISS Spectrum CMM

Measuring Volume: 27.6 × 39.4 × 23.6 in
Accuracy (MPE): ~0.071 + L(in)/9.84 µm (up to ~0.067 + L(in)/7.62 µm)
Angular Positions: 5° step = 5,184 / 2.5° step = 20,736
Sensors: RDS-CAA, VAST XXT, LineScan One (optical)
Software: ZEISS CALYPSO

2D Height Master

TRIMOS V7 Height Gauge

Measuring Range: 700 mm
Measuring Range with Probe Inverted: 1023 mm
Max Permissible Error (MPE): 2 µm + L(mm)/400
Max Permissible Error (MPE): 2.5 µm + L(mm)/300
Repeatability (2s): 1 µm (flat), 2 µm (cylindrical)
Frontal Squareness Deviation (700 mm): 8 µm
Resolution: 0.0001 mm (0.1 µm)

TRIMOS V7 Height Gauge

Measuring Range: 28 in
Measuring Range with Probe Inverted: 40.3 in
Max Permissible Error (MPE): 0.00008 in + L(in)/15.7
Max Permissible Error (MPE): 0.0001 in + L(in)/11.8
Repeatability (2s): 0.00004 in (flat), 0.00008 in (cylindrical)
Frontal Squareness Deviation (28 in): 0.0003 in
Resolution: 0.00001 in

We are a leading engineering organisation engaged in the manufacturing of precision components, where Quality is at the heart of every aspect of each component that we make at the benchmark of reliability.
